Viessmann VITOPLEX 300 Type TX3A - 8. Burner; 8.1 Specification, Vitoflame 100, type VEH III

8.1 Specification, Vitoflame 100, type VEH III
Burner output stage 1/2
Corresponds to the rated thermal load of the boiler.
Vitoflame 100 pressure-jet oil burner in conjunction with a Vitoplex 200
Rated boiler output kW 90 120 150 200 270
Burner output
First/second stage
kW 68/97 91/130 114/163 152/217 205/293
Burner type VEH III-1SX VEH III-2SX VEH III-3SX VEH III-4SX VEH III-5SX
Oil throughput
Stage 1 kg/h 5.8 7.7 9.6 12.8 17.2
l/h 6.8 9.1 11.3 15.1 20.2
Stage 2 kg/h 8.2 11.0 13.7 18.3 24.6
l/h 9.6 12.9 16.1 21.5 28.9
Type test no. to EN 267 G1037/08S
Voltage V 230
Frequency Hz 50
Motor speed rpm 2800
Version Two-stage
Oil pump rate l/h 70
Dimensions
Length (dimension a) mm 418
Width mm 400
Height (dimension b) mm 538
Weight kg 26
Connections
Suction and return lines on the supplied oil
hoses
R
⅜
Max. permissible pre-charge pressure
in the supply lines
(for looped lines)
bar 2
Vitoflame 100 pressure-jet oil burner in conjunction with a Vitoplex 300
Rated output
of the boiler
kW 90 115 140 180 235 300
Burner output
First/second stage
kW 68/98 88/125 106/152 137/196 179/255 228/326
Burner type VEHIII-1TXA VEHIII-2TXA VEHIII-3TXA VEHIII-4TXA VEHIII-5TXA VEHIII-6TXA
Oil throughput
Stage 1 kg/h 5.2 7.4 10.6 11.6 15.0 18.2
l/h 6.1 8.7 12.5 13.7 17.7 21.4
Stage 2 kg/h 7.4 10.5 12.8 16.4 21.5 26.1
l/h 8.7 12.4 15.1 19.3 25.3 30.7
Type test no. to EN 267 G1037/08S
Voltage V 230
Frequency Hz 50
Motor speed rpm 2800
Version Two-stage
Oil pump rate l/h 70
Dimensions
Length (dimension a) mm 418
Width mm 400
Height (dimension b) mm 538
Weight kg 26
Connections
Suction and return lines on the supplied
oil hoses
R
⅜
Max. permissible pre-charge pres-
sure
in the supply lines
(for looped lines)
bar 2
