Vitoflame 100 pressure-jet oil burner in conjunction with a Vitoradial 300-T
Rated output
T
V
/T
R
= 50/30°C kW 101 129 157 201 263 335
T
V
/T
R
= 80/60°C kW 94 120 146 188 245 313
Burner output
First/second stage
kW 68/98 88/125 106/152 137/196 179/254 228/326
Burner type VEHIII-1TXA VEHIII-2TXA VEHIII-3TXA VEHIII-4TXA VEHIII-5TXA VEHIII-6TX
A
Oil throughput
Stage 1 kg/h 5.2 7.4 10.6 11.6 15.0 18.2
l/h 6.1 8.7 12.5 13.7 17.7 21.4
Stage 2 kg/h 7.4 10.5 12.8 16.4 21.5 26.1
l/h 8.7 12.4 15.1 19.3 25.3 30.7
Type test no. to EN 267 G1037/08S
Voltage V 230
Frequency Hz 50
Motor speed rpm 2800
Version Two-stage
Oil pump rate l/h 70
Dimensions
Length (dimension a) mm 418
Width mm 400
Height (dimension b) mm 538
Weight kg 26
Connections
Suction and return lines on the supplied oil
hoses
R
⅜
Max. permissible pre-charge pressure
in the supply lines
(for looped lines)
bar 2
Vitoflame 100 pressure-jet oil burner in conjunction with a Vitorond 200
Rated output
of the boiler
kW 125 160 195 230 270
Burner output
First/second stage
kW 95/136 122/174 149/213 175/250 205/293
Burner type VEH III-1VD VEH III-2VD VEH III-3VD VEH III-4VD VEH III-5VD
Oil throughput
Stage 1 kg/h 8.0 11.7 12.5 14.7 17.2
l/h 9.4 13.8 14.7 17.3 20.2
Stage 2 kg/h 11.4 14.6 17.8 21.0 24.6
l/h 13.4 17.2 20.9 24.7 28.9
Type test no. to EN 267 G1037/08S
Voltage V 230
Frequency Hz 50
Motor speed rpm 2800
Version Two-stage
Oil pump rate l/h 70
Dimensions
Length (dimension a) mm 418
Width mm 400
Height (dimension b) mm 538
Weight kg 26
Connections
Suction and return lines on the supplied oil
hoses
R
⅜
Max. permissible pre-charge pressure
in the supply lines
(for looped lines)
bar 2
Approved quality
CE designation according to current EC Directives.
Burner
(cont.)
