16:10 Image on a 4:3 Screen
(a) Screen
Size
(b) Projection Distance (c) Image
Height
(d) Vertical Offset
minimum maximum minimum maximum
in. mm in. mm in. mm in. mm in. mm in. mm
30 762 29 735 38 956 15 381 1.5 38 1.5 38
40 1016 39 980 50 1274 20 508 2.0 51 2.0 51
50 1270 48 1225 63 1593 25 635 2.5 64 2.5 64
60 1524 58 1470 75 1912 30 762 3.0 76 3.0 76
70 1778 68 1715 88 2230 35 889 3.5 89 3.5 89
80 2032 77 1961 100 2549 40 1016 4.0 102 4.0 102
90 2286 87 2206 113 2867 45 1143 4.5 114 4.5 114
100 2540 96 2451 125 3186 50 1270 5.0 127 5.0 127
110 2794 106 2696 138 3504 55 1397 5.5 140 5.5 140
120 3048 116 2941 151 3823 60 1524 6.0 152 6.0 152
130 3302 125 3186 163 4142 65 1651 6.5 165 6.5 165
140 3556 135 3431 176 4460 70 1778 7.0 178 7.0 178
150 3810 145 3676 188 4779 75 1905 7.5 191 7.5 191
160 4064 154 3921 201 5097 80 2032 8.0 203 8.0 203
170 4318 164 4166 213 5416 85 2159 8.5 216 8.5 216
180 4572 174 4411 226 5735 90 2286 9.0 229 9.0 229
190 4826 183 4656 238 6053 95 2413 9.5 241 9.5 241
200 5080 193 4901 251 6372 100 2540 10.0 254 10.0 254
250 6350 241 6127 314 7965 125 3175 12.5 318 12.5 318
300 7620 289 7352 376 9558 150 3810 15.0 381 15.0 381
NOTE: There is a 3% tolerance among these numbers due to optical component
variations. It is recommended to physically test the projection size and
distance before permanently installing the projector.
