LED Indicators
Light Status and Description
Power
Green
Flashing
Off Off Stand-by mode
Green Off Off Powering up
Green Off Off Normal operation
Green
Flashing
Off Off Normal power-down cooling
Red Off Off Downloading
Green Green Green Burn in off
Lamp
Green
Flashing
Off Red First light source-lit error cooling
Off Off Red Light source error in normal operation
Green Off Red Color wheel start has failed
Heating/Cooling
Off Red Off Fan 1 error (actual fan speed is outside the desired speed).
Off Red Red Fan 2 error (actual fan speed is outside the desired speed).
Off Red Green Fan 3 error (actual fan speed is outside the desired speed).
Off Red Orange Fan 4 error (actual fan speed is outside the desired speed).
Red
Flashing
Red Off Fan 5 error (actual fan speed is outside the desired speed).
Red
Flashing
Red
Flashing
Off Fan 6 error (actual fan speed is outside the desired speed).
Red Red Red Thermal sensor 1 open error (the remote diode has an
open-circuit condition).
Red Red Green Thermal sensor 2 open error (the remote diode has an
open-circuit condition).
Green Red Red Thermal sensor 1 short error (the remote diode has an
open-circuit condition).
Off Red Green Thermal sensor 2 short error (the remote diode has an
open-circuit condition).
Orange Red Red Temperature 1 error (over limited temperature).
Orange Red Green Temperature 2 error (over limited temperature).
Off Green Red Fan IC #1 I2C connection error.
