ViewSonic PG707W User Manual

34
Adjusting the Projected Image
Adjusting the Projector's Height and Projection Angle
The projector is equipped with one (1) adjuster foot. Adjusting the foot will change
the projector’s height and the vertical projection angle. Carefully adjust the feet to
fine tune the projected image’s position.
Auto-Adjusting the Image
Sometimes, you may need to improve the picture quality. To do this, press Auto
Sync on the remote control. Within five (5) seconds, the built-in Intelligent Auto
Adjustment function will re-adjust the Frequency and Clock values to provide the
best picture quality.
Upon completion, the current source information will appear in the upper left
corner for three (3) seconds.
NOTE: This funcon is only available when the PC D-Sub input source (analog RGB/
COMPUTER IN) is selected.
Fine-Tuning the Image Size and Clarity
To adjust the projected image to the size that you need, rotate the Zoom Ring.
To improve the clarity of the image, rotate the Focus Ring.

ViewSonic PG707W Specifications

General

Type	lamp
Color	white
Display	dlp
Throw Type	standard throw
Portable	fixed
White Brightness	4000 lumens
Resolution	800p
Native Resolution	1280 x 800
Contrast Ratio	22000:1
Aspect Ratio	16:10
Throw Ratio Range	1.21 -1.57:1
Minimum Screen Size	29.9 inches
Maximum Screen Size	300 inches
HDMI Ports	1
Video Input	composite video, hdmi, vga
Inputs	usb, composite video, vga, rca, 3.5mm audio
Built In Speakers	yes
Speakers Output	10 watts
Remote Control	yes
OS Compatibility	none

Weight and Dimensions

Depth	8.6 inches
Height	4.3 inches
Width	11.6 inches
Net Weight	5.1 pounds
