... continue function-no. input range (channel 0, channel 1)
No. Function Measuring range / representation
7Dh Voltage 0...10V
Siemens S7 format
(two’s complement)
0...11.76V
11.76V= End overdrive region (32511)
0...10V = nominal range (0...27648)
no underdrive region available
3Ah
Current ±20mA
Siemens S5 format
(two’s complement)
±25.0mA /
25.0mA = End overdrive region (20480)
-20...20mA = nominal range (-16384...16384)
-25.0mA = End underdrive region (-20480)
2Fh
Current ±20mA
Siemens S5 format
(value and sign)
±25.0mA /
25.0mA = End overdrive region (20480)
-20...20mA = nominal range (-16384...16384)
-25.0mA = End underdrive region (-20480)
2Eh Current 4...20mA
Siemens S5 format
(value and sign)
0.8...+24.0mA /
24.0mA = End overdrive region(20480)
4 ... 20mA = nominal range (0...16384)
0.8mA = End underdrive region (-3277)
76h Current 0...20mA
Siemens S5 format
(value and sign)
0...25mA
25mA = End overdrive region (20480)
0...20mA = nominal range (0...16384)
no underdrive region available
2Ch
Current ±20mA
Siemens S7 format
(two’s complement)
±23.51mA /
23.51mA = End overdrive region (32511)
-20...20mA = nominal range (-27648...27648)
-23.51mA = End underdrive region (-32512)
2Dh Current 4...20mA
Siemens S7 format
(two’s complement)
1.185...+22.81mA /
22.81mA = End overdrive region (32511)
4...20mA = nominal range (0...27648)
1.18mA = End underdrive region (-4864)
7Eh Current 0...20mA
Siemens S7 format
(two’s complement)
0...23.52mA
23.52mA = End overdrive region (32511)
0...20mA = nominal range (0...27648)
no underdrive region available
FFh Channel not active (turned off)
Note!
The module is preset to the range "±10V voltage" in S7 format from
Siemens.
