Chapter 5 238-2BC00 - Combination module Manual VIPA System 200V
5-2 HB97E - SM-AIO - Rev. 12/32
Overview
The combination module includes a digital in-/output module with counter
function and an analog in-/output module.
The following components are integrated:
• Analog input: 3xU/I, 1xPT100x12Bit
• Analog output: AO 2x12Bit COM
• Digital input: 16(12)xDC24V with parameterizable counter functions
• Digital output: 0(4)xDC24V 1A
• Counter: max. 3 counter with the operating modes: endless,
single or periodic counting.
Security hints for deploying I/O channels!
Please regard that the voltage applied to an output channel must be ≤ the
voltage supply applied to L+.
Due to the parallel connection of in- and output channel, a set output
channel may be supplied via an applied input signal. Thus, a set output
remains active even at power-off of the voltage supply with the applied
input signal.
Non-observance may cause module demolition.
The combination module can only be used together with a CPU 21x or with
the DP-V1 PROFIBUS coupler (253-xDP01)! Here the max. number of
modules is limited to 2.
The operation at a other bus coupler is not permitted.
The necessary GSD files can be found at the "service" area under
www.vipa.com.
The project engineering takes place in the Siemens SIMATIC manager. For
this the import of the corresponding GSD file is required.
After installation of the GSD the combination module can be found at the
hardware catalog at:
Additional Field devices > I/O > VIPA_System_200V >...
as 2 modules:
238-2BC00 (1/2) AI4/AO2*12Bit
238-2BC00 (2/2) Counter
For the module has a digital and an analog part, you have to configure for
each one component during the hardware configuration.
The control of the counter happens via digital input channels. For the
counter you may configure alarms that influence one digital output channel
per counter.
DI 16xDC24V / AI 4/AO 2x12Bit Combination module VIPA 238-2BC00
General
Project
engineering
Counter
Ordering data
