Manual VIPA System 200V Chapter 4 Analog input/output modules
HB97E - SM-AIO - Rev. 12/32 4-15
Order number 234-1BD50
Basic error limit voltage ranges with SFU +/-0.2% ... +/-0.6%
Current outputs
9
Max. in load resistance (current range) 500 Ω
Max. inductive load (current range) 10 mH
Output current ranges -20 mA ... +20 mA
+4 mA ... +20 mA
0 mA ... +20 mA
Operational limit of current ranges -
Basic error limit current ranges with SFU +/-0.3% ... +/-0.8%
Settling time for ohmic load 0.05 ms
Settling time for capacitive load 0.5 ms
Settling time for inductive load 0.1 ms
Resolution in bit 12
Conversion time 2.5 ms/all channels
Substitute value can be applied yes
Output data size 4 Byte
Status information, alarms, diagnostics
Status display none
Interrupts yes
Process alarm no
Diagnostic interrupt yes, parameterizable
Diagnostic functions yes
Diagnostics information read-out possible
Supply voltage display green LED
Group error display red SF LED
Channel error display none
Isolation
Between channels -
Between channels of groups to -
Between channels and backplane bus
9
Between channels and power supply
9
Max. potential difference between circuits -
Max. potential difference between inputs (Ucm) -
Max. potential difference between Mana and Mintern
(Uiso)
DC 75 V/ AC 60 V
Max. potential difference between inputs and Mana
(Ucm)
-
Max. potential difference between inputs and Mintern
(Uiso)
-
Max. potential difference between Mintern and
outputs
-
Insulation tested with DC 500 V
Datasizes
Input bytes 4
Output bytes 4
Parameter bytes 14
Diagnostic bytes 12
Housing
Material PPE / PA 6.6
Mounting Profile rail 35 mm
Mechanical data
Dimensions (WxHxD) 25.4 x 76 x 88 mm
Weight 110 g
Environmental conditions
Operating temperature 0 °C to 60 °C
Storage temperature -25 °C to 70 °C
Certifications
UL508 certification yes
