Manual VIPA System 200V Chapter 4 Analog input/output modules
HB97E - SM-AIO - Rev. 12/32 4-21
The assignment of a function-no. to a certain channel happens during
parameterization. The function-no. 00h does not influence the function-no.
stored in the permanent parameterization data.
By entering FFh you may deactivate the concerning channel.
The following tables list all functions that are supported by the depending
channel.
You may find the connection type mentioned under "connection" at the
"circuit diagram" above.
Note!
When exceeding the overdrive region, the value 7FFFh (32767) is thrown,
at underrun of the underdrive region the value is 8000h (-32768).
Input range (channel 0 … 2)
No. Function Measuring range / representation Connection
00h Does not affect permanently stored configuration data.
7Dh Voltage 0 … 10V
Siemens S7 format
(two’s complement)
-1.76 … 11.76V /
11.76V= End overdrive region (32511)
0...10V= nominal range (0...27648)
-1.76V= End underdrive region (-4864)
(1)
7Ah Voltage 1 … 5V
Siemens S7 format
(two’s complement)
0.3 … 5.70V /
5.70V= End overdrive region (32511)
1...5V= nominal range (0...27648)
0.30V= End underdrive region (-4864)
(1)
28h
Voltage ±10V
Siemens S7 format
(two’s complement)
±11.76V /
11.76V= End overdrive region (32511)
-10...10V= nominal range (-27648...27648)
-11.76V= End underdrive region (-32512)
(1)
29h
Voltage ±4V
Siemens S7 format
(two’s complement)
±4.70V /
4.70V= End overdrive region (32511)
-4...4V= nominal range (-27648...27648)
-4.70V= End underdrive region (-32512)
(1)
2Ah
Voltage ±400mV
Siemens S7 format
(two’s complement)
±470mV /
470mV= End overdrive region (32511)
-400...400mV= nominal range (-27648...27648)
-470mV= End underdrive region (-32512)
(1)
7EH Current 0 … 20mA
Siemens S7 format
(two’s complement)
-3.51 … 23.51mA /
23.51mA = End overdrive region (32511)
0...20mA = nominal range (0...27648)
-3.51mA = End underdrive region (-4864)
(2)
2Ch
Current ±20mA
Siemens S7 format
(two’s complement)
±23.51mA /
23.51mA = End overdrive region (32511)
-20...20mA = nominal range (-27648...27648)
-23.51mA = End underdrive region (-32512)
(2)
2Dh Current 4...20mA
Siemens S7 format
(two’s complement)
1.185...+22.81mA /
22.81mA = End overdrive region (32511)
4...20mA = nominal range (0...27648)
1.18mA = End underdrive region (-4864)
(2)
FFh Channel not active (turned off)
Function-no.
assignment
