Chapter 5 238-2BC00 - Combination module Manual VIPA System 200V
5-42 HB97E - SM-AIO - Rev. 12/32
Order number 238-2BC00
Noise suppression for frequency 50 Hz and 60 Hz
Initial data size 8 Byte
Technical data analog outputs
Number of outputs 2
Cable length, shielded 200 m
Rated load voltage DC 24 V
Reverse polarity protection of rated load voltage
9
Current consumption from load voltage L+ (without
load)
70 mA
Voltage output short-circuit protection
9
Voltage outputs
9
Min. load resistance (voltage range) 1 kΩ
Max. capacitive load (current range) 1 µF
Output voltage ranges -10 V ... +10 V
+1 V ... +5 V
0 V ... +10 V
Operational limit of voltage ranges +/-0.4% ... +/-0.8%
Basic error limit voltage ranges with SFU +/-0.2% ... +/-0.4%
Current outputs
9
Max. in load resistance (current range) 500 Ω
Max. inductive load (current range) 10 mH
Output current ranges -20 mA ... +20 mA
0 mA ... +20 mA
0 mA ... +20 mA
Operational limit of current ranges +/-0.3% ... +/-0.8%
Basic error limit current ranges with SFU +/-0.2% ... +/-0.5%
Settling time for ohmic load 0.3 ms
Settling time for capacitive load 1 ms
Settling time for inductive load 0.5 ms
Resolution in bit 12
Conversion time 1.50 ms
Substitute value can be applied yes
Output data size 4 Byte
Status information, alarms, diagnostics
Status display yes
Interrupts yes
Process alarm yes, parameterizable
Diagnostic interrupt yes, parameterizable
Diagnostic functions yes
Diagnostics information read-out possible
Supply voltage display green LED per group
Group error display red SF LED
Channel error display none
Isolation
Between channels -
Between channels of groups to -
Between channels and backplane bus
9
Between channels and power supply
9
Max. potential difference between circuits -
Max. potential difference between inputs (Ucm) DC 4 V
Max. potential difference between Mana and
Mintern (Uiso)
-
Max. potential difference between inputs and Mana
(Ucm)
-
Max. potential difference between inputs and
Mintern (Uiso)
DC 75 V/ AC 60 V
Max.
otential difference between Mintern and -
