Chapter 2 Analog input modules Manual VIPA System 200V
2-14 HB97E - SM-AIO - Rev. 12/32
Order number 231-1BD40
Max. potential difference between inputs (Ucm) DC 2 V
Max. potential difference between Mana and
Mintern (Uiso)
-
Max. potential difference between inputs and Mana
(Ucm)
-
Max. potential difference between inputs and
Mintern (Uiso)
DC 75 V/ AC 60 V
Max. potential difference between Mintern and
outputs
-
Insulation tested with DC 500 V
Datasizes
Input bytes 8
Output bytes 0
Parameter bytes 12
Diagnostic bytes 0
Housing
Material PPE / PA 6.6
Mounting Profile rail 35 mm
Mechanical data
Dimensions (WxHxD) 25.4 x 76 x 88 mm
Weight 90 g
Environmental conditions
Operating temperature 0 °C to 60 °C
Storage temperature -25 °C to 70 °C
Certifications
UL508 certification yes
