Manual VIPA System 200V Chapter 2 Analog input modules
HB97E - SM-AIO - Rev. 12/32 2-27
Order number 231-1BD53
Resolution in bit 16
Measurement principle Sigma-Delta
Basic conversion time 7 ms ... 272 ms
Noise suppression for frequency none
Initial data size 8 Byte
Status information, alarms, diagnostics
Status display none
Interrupts yes
Process alarm no
Diagnostic interrupt yes, parameterizable
Diagnostic functions yes
Diagnostics information read-out possible
Supply voltage display none
Group error display none
Channel error display red LED per channel
Isolation
Between channels -
Between channels of groups to -
Between channels and backplane bus
9
Between channels and power supply -
Max. potential difference between circuits -
Max. potential difference between inputs (Ucm) DC 4 V
Max. potential difference between Mana and
Mintern (Uiso)
-
Max. potential difference between inputs and Mana
(Ucm)
-
Max. potential difference between inputs and
Mintern (Uiso)
DC 75 V/ AC 60 V
Max. potential difference between Mintern and
outputs
-
Insulation tested with DC 500 V
Datasizes
Input bytes 8
Output bytes 0
Parameter bytes 12
Diagnostic bytes 12
Housing
Material PPE / PA 6.6
Mounting Profile rail 35 mm
Mechanical data
Dimensions (WxHxD) 25.4 x 76 x 88 mm
Weight 100 g
Environmental conditions
Operating temperature 0 °C to 60 °C
Storage temperature -25 °C to 70 °C
Certifications
UL508 certification yes
