Chapter 2 Analog input modules Manual VIPA System 200V
2-54 HB97E - SM-AIO - Rev. 12/32
... continue
Byte Bit 7 ... Bit 0 Default
10 Bit 2 ... 0: mean value
000: disabled
001: mean value over 2 values
010: mean value over 4 values
011: mean value over 8 values
100: mean value over 16 values
101, 011, 111: disabled
Bit 7 ... 3: reserved
00h
11-15 reserved 00h
16 channel 0, upper limit, High-Byte 7Fh
17 channel 0, upper limit, Low-Byte FFh
18 channel 0, lower limit, High-Byte 80h
19 channel 0, lower limit, Low-Byte 00h
20 channel 1, upper limit, High-Byte 7Fh
21 channel 1, upper limit, Low-Byte FFh
22 channel 1, lower limit, High-Byte 80h
23 channel 1, lower limit, Low-Byte 00h
24 channel 2, upper limit, High-Byte 7Fh
25 channel 2, upper limit, Low-Byte FFh
26 channel 2, lower limit, High-Byte 80h
27 channel 2, lower limit, Low-Byte 00h
28 channel 3, upper limit, High-Byte 7Fh
29 channel 3, upper limit, Low-Byte FFh
30 channel 3, lower limit, High-Byte 80h
31 channel 3, lower limit, Low-Byte 00h
