Order no. 312-5BE13
S7 communication as server
ü
S7 communication as client -
S7 communication, user data per job 160 Byte
Number of connections, max. 32
PWM data
PWM channels 2
PWM time basis 0.1ms/1ms
Period length 4...65535 / 1...65535 * timebase
Minimum pulse width 0...0.5*period
Type of output Highside with 1.1kOhm pulldown
Functionality Sub-D interfaces
Type X2
Type of interface RS485
Connector Sub-D, 9-pin, female
Electrically isolated -
MPI
ü
MP²I (MPI/RS232) -
DP master -
DP slave -
Point-to-point interface -
Type X3
Type of interface RS485
Connector Sub-D, 9-pin, female
Electrically isolated
ü
MPI -
MP²I (MPI/RS232) -
DP master -
DP slave -
Point-to-point interface
ü
Functionality MPI
Number of connections, max. 32
PG/OP channel
ü
Routing -
Global data communication
ü
S7 basic communication
ü
VIPA System 300SHardware description
Technical data
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 42
