Event-ID Description
0xE804 CMD - Auto command: WEBPAGE recognized and successfully executed
0xE805 CMD - Auto command: LOAD_PROJECT recognized and successfully exe-
cuted
0xE806 CMD - Auto command: SAVE_PROJECT
Zinfo3: 0x0000: SAVE_PROJECT recognized and successfully executed
Zinfo3: 0x8000: Error during SAVE_PROJECT e.g. wrong password
0xE807 CMD - Auto command: FACTORY_RESET recognized and successfully
executed
0xE80B CMD - Auto command: DIAGBUFF recognized and successfully executed
0xE80E CMD - Auto command: SET_NETWORK recognized and successfully exe-
cuted
0xE816 CMD - Auto command: SAVE_PROJECT: Error - CPU has been reset - no
wld file was created.
0xE8FB CMD - Auto command: Error: Initialization of the Ethernet PG/OP channel
by means of SET_NETWORK is faulty
0xE8FC CMD - Auto command: Error: Some IP parameters missing in SET_NET-
WORK
0xE8FE CMD - Auto command: Error: CMD_START missing
0xE8FF CMD - Auto command: Error: Error while reading CMD file (memory card
error)
0xE901 Check sum error
0xEA00 Internal error - Please contact the VIPA Hotline!
0xEA01 Internal error - Please contact the VIPA Hotline!
0xEA02 SBUS: Internal error (internal plugged sub module not recognized)
ZInfo1: Internal slot
0xEA03 SBUS: Communication error CPU - PROFINET I/O controller:
ZInfo1: Slot
ZInfo2: Status
(0: OK, 1: ERROR, 2: BUSY, 3: TIMEOUT, 4: LOCKED, 5: UNKNOWN)
0xEA04 SBUS: Multiple parametrization of a periphery address
ZInfo1: Periphery address
ZInfo2: Slot
ZInfo3: Data width
0xEA05 Internal error - Please contact the VIPA Hotline!
0xEA07 Internal error - Please contact the VIPA Hotline!
VIPA System 300SDeployment CPU 312-5BE13
VIPA specific diagnostic entries
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 76
