Event-ID Description
0xEA08 SBUS: Parametrized input data width unequal to plugged input data width
ZInfo1: Parametrized input data width
ZInfo2: Slot
ZInfo3: Input data width of the plugged module
0xEA09 SBUS: Parametrized output data width unequal to plugged output data width
ZInfo1: Parametrized output data width
ZInfo2: Slot
ZInfo3: Output data width of the plugged module
0xEA10 SBUS: Input periphery address outside the periphery area
ZInfo1: Periphery address
ZInfo2: Slot
ZInfo3: Data width
0xEA11 SBUS: Output periphery address outside the periphery area
ZInfo1: Periphery address
ZInfo2: Slot
ZInfo3: Data width
0xEA12 SBUS: Error at writing record set
ZInfo1: Slot
ZInfo2: Record set number
ZInfo3: Record set length
0xEA14 SBUS: Multiple parametrization of a periphery address (diagnostics
address)
ZInfo1: Periphery address
ZInfo2: Slot
ZInfo3: Data width
0xEA15 Internal error - Please contact the VIPA Hotline!
0xEA18 SBUS: Error at mapping of the master periphery
ZInfo2: Slot of the master
0xEA19 Internal error - Please contact the VIPA Hotline!
0xEA20 Error - RS485 interface is not pre-set to PROFIBUS DP master bus a
PROFIBUS DP master is configured.
0xEA21 Error - Configuration RS485 interface X2/X3:
PROFIBUS DP master is configured but missing
ZInfo2: Interface x
0xEA22 Error - RS485 interface X2 - Value exceeds the limits
ZInfo: Configured value of X2
0xEA23 Error - RS485 interface X3 - Value exceeds the limits
ZInfo: Configured value of X3
VIPA System 300S Deployment CPU 312-5BE13
VIPA specific diagnostic entries
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 77
