Event-ID Description
0xEC11 EtherCAT: Restoration bus with missing slaves
OB start Info (Local data) StartEvent and Eventclass: 0xEC11
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics address of the master
ZInfo3: Number of stations, which are not in the same state as the master
(> 0)
0xEC12 EtherCAT: restoration slave
OB start Info (Local data) StartEvent and Eventclass: 0xEC12
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics of the Station
ZInfo3: AlStatusCode
0xEC30 EtherCAT: Topology OK
OB start Info (Local data) StartEvent and Eventclass: 0xEC30
ZInfo2: Diagnostics address of the master
0xEC50 EtherCAT: DC not in Sync
ZInfo1: Diagnostics address of the master
0xED10 EtherCAT: Bus failure
OB start Info (Local data) StartEvent and Eventclass: 0xED10
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics address of the master
ZInfo3: Number of stations, which are not in the same state as the master
