Event-ID Description
0xED12 EtherCAT: Failure slave
OB start Info (Local data) StartEvent and Eventclass: 0xED12
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics of the Station
ZInfo3: AlStatusCode
0xED20 EtherCAT: Bus state change without calling OB86
OB start Info (Local data) StartEvent and Eventclass: 0xED20
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics address of the master
ZInfo3: Number of stations, which are not in the same state as the master
0xED21 EtherCAT: error in bus state change
OB: 0x00
PK: 0x00
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX = current state, YY = expected state)
ZInfo2: Diagnostics address of the master
ZInfo3: ErrorCode:
0x0008: Busy
0x000B: Invalid Parameter
0x000E: Invalid State
0x0010: Timeout
VIPA System 300S Deployment CPU 312-5BE13
VIPA specific diagnostic entries
