Event-ID Description
0xED22 EtherCAT: Bus state change without calling OB86
OB start Info (Local data) StartEvent and Eventclass: 0xED22
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics of the Station
ZInfo3: AlStatusCode
0xED30 EtherCAT: Topology Mismatch
OB start Info (Local data) StartEvent and Eventclass: 0xED30
ZInfo2: Diagnostics address of the master
0xED31 EtherCAT: Interrupt Queue Overflow
OB start Info (Local data) StartEvent and Eventclass: 0xED31
ZInfo2: Diagnostics address of the master
0xED40 ... 0xED4F Internal error - Please contact the VIPA Hotline!
0xED50 EtherCAT: DC not in Sync
ZInfo1: Diagnostics address of the master
0xED60 EtherCAT: Diagnostics buffer CP:
Slave state change
PK: 0
OB: PLC-Mode
DatID 1/2: 0
ZInfo1: 0x00YY:
YY: New EtherCAT state of the slave
ZInfo2: EtherCAT station address
ZInfo3: AlStatusCode (EtherCAT specific error code)
VIPA System 300SDeployment CPU 312-5BE13
VIPA specific diagnostic entries
