Event-ID Description
0xED61 EtherCAT: Diagnostics buffer CP:
CoE emergency
PK: EtherCAT station address (low byte)
OB: EtherCAT station address (high byte)
DatID 1/2: Error code
ZInfo1: 0xYYZZ:
YY: Error register
ZZ: MEF byte 1
ZInfo 2: 0xYYZZ:
YY: MEF byte 2
ZZ: MEF byte 3
ZInfo3: 0xYYZZ:
YY: MEF byte 4
ZZ: MEF byte 5
0xED62 EtherCAT: Diagnostics buffer CP:
Error on SDO access during state change
PK: EtherCAT station address (low byte)
OB: EtherCAT station address (high byte)
DatID 1/2: Subindex
ZInfo1: Index
ZInfo2: SDO error code (high word)
ZInfo3: SDO error code (low word)
0xED70 EtherCAT: Diagnostics buffer CP:
Twice HotConnect group found
PK: 0
OB: PLC-Mode
DatID 1/2: 0
ZInfo1: Diagnostics address of the master
ZInfo2: EtherCAT station address
ZInfo3: 0
0xEE00 Additional information at UNDEF_OPCODE
0xEE01 Internal error - Please contact the VIPA Hotline!
0xEEEE CPU was completely overall reset, since after PowerON the start-up could
not be finished.
0xEF11 ... 0xEF13 Internal error - Please contact the VIPA Hotline!
VIPA System 300S Deployment CPU 312-5BE13
VIPA specific diagnostic entries
