ViscoTec RD-EC - Dimensions; Disposal

Version 1.2
Operating and Assembly Instructions
Dispenser RD-EC 27 / 27
7.4 Dimensions
8 Disposal
Dispose of the dispenser in an environmentally safe way. All materials and products left
in containers must be treated in accordance with the appropriate recycling requirements.
4RD6 3RD8 3RD10 3RD12
X, mm 211 211 237 271
Y, mm 135 161 195
L 76
1B G 1/4" * G 3/8“ *
1A G 1/2" *
B ** 14 k6
* Cylindrical Whitworth pipe thread DIN / ISO 228
** Shaft Ø maximum, mm
Field for the type plate sticker for
this dispenser
12345
12345
X
Y
1A
1B
B
L
Fig. 14
