Operating instructions, Quick installation
When gross weight is displayed the letter 'G' is shown
under the measurement value.
Press key ↑ .
Additional functions for the scale will appear
to the right on the bottom line.
Use key + or – to scroll to 'B/N'.
Press key ↵ to change to display of net weight.
143.2 kg
S1:G
143.2 kg
S1:G B/N
Note: If the tare value is zero, net weight cannot be displayed.
When net weight is displayed, the letter 'N' is shown
under the measurement value.
Press key ↑ .
Additional functions for the scale will appear
to the right on the bottom line.
Use key + or – to scroll to 'B/N'.
Press key ↵ to change to display of gross weight.
Gross weight is displayed.
103.2 kg
S1:N
103.2 kg
S1:N B/N
143.2 kg
S1:G
Taring
Taring means storing of a tare value for the scale. Net weight will be calculated as
the difference between the gross weight and this tare value. If the tare value is zero,
net weight will not be displayed.
At default setting, taring can always be performed if parameter 'Tare key' is set to 'On'.
This makes the additional function 'Tare' available for the scale.
But the scale can also be set to allow taring only at stable weight (letter 'M' not shown).
In G4 two tare values can be stored, Auto tare and Preset tare.
Auto tare
By taring, the actual gross weight is stored as Auto tare value, and the scale will switch
to display of net weight 'zero'.
Press key ↑. Additional functions for the scale will
appear to the right on the bottom line.
Use key + or – to scroll to 'Tare'.
Press key ↵ to perform taring.
In this example 14.5 kg is stored as an auto tare
value.
014.5 kg
S1:G Tare
000.0 kg
S1:N Z
6
