Vishay G4 - Scale Calibration Introduction

G4 Multi Channel Weighing Instrument
Scale calibration
All calibration set-up parameters are set individually for each scale. The scale number
is used to distinguish parameters for different scales. The following example shows a
set-up sequence for Scale 1, so all parameters will begin with 1: .
Individual parameters for the scales are found in menu 'Calibration',
a sub menu to 'Param. Set-up'.
('Param. Set-up' is a sub menu to the 'Main Menu'. To open 'Main Menu' from normal
weight display, press the keys + and ↑ simultaneously for 1 second.)
In 'Main Menu', use key + or –
to find sub menu 'Param. Set-up'.
Press key ↵ .
In 'Param. Set-up', use key + or –
to find sub menu 'Calibration'.
Press key ↵ .
Sub menu 'Calibration' contains settings
for the scales that are in use.
Use the keys + and – to find the desired
scale number, in this example Scale 1.
Main Menu
Param.Set-up
Param.Set-up
Calibration
Calibration
Scale 1
Press key ↵ .
As 'Scale 1' has been selected, the keys + and – can be used
to scroll the list of set-up parameters for the scale.
Some basic parameters are explained on the following pages.
Press key ↵ to perform editing of the displayed parameter.
The Operator Code or the Set-up Code may be needed to continue.
25
