Operating instructions, Quick installation
Weight Printing
A printer can be used to print the displayed weight or the displayed flow rate. The
printer must be connected to one of the G4 Instrument serial communication ports and
the communication parameters must be correctly set.
This example shows how to make a print out of the displayed weight for Scale 1 (the
displayed scale) from VIEWPAN.
Scale 1 is selected and in normal weighing operation.
Press key ↑ to see Additional functions.
Use key + or – to find the additional function 'Print'.
Press key ↵ .
The displayed weight value is printed, indicated
by a 'P' in the display.
033.2 kg
S1:N
033.2 kg
S1:N Print
033.2 kg
S1:N P
The print indicator ‘P’ is shown where the ‘Z’ (zero) or ‘M’ (motion) indications normally
appear. The print indication will appear even if no printer is configured and indicates
that the weight is accumulated.
Print out will be performed provided that:
• The displayed weight is higher than the value of 'Min. Weight Print'. No print out
will be done if the weight is too low.
• If 'Motion Check' is turned on, the displayed weigh must be stable ('M' not
shown).
If the weight is not stable ('M' shown), printing will be delayed and the 'P' will be
flashing. When the weight has become stable ('M' not shown) printing will be
performed.
8
