G4 Multi Channel Weighing Instrument
Exit calibration.
To exit from calibration, press key ↑ twice.
A question, 'Save calib?', is displayed.
Save calib?
Answer Yes (key ↵ ) to keep the new settings
in the instrument memory, or
No Esc. Yes
answer No (key – ) to exit calibration without saving
(all changes will be rejected).
In both cases the instrument switches to sub menu 'Calibration'.
Answer Esc. (key ↑ ) to continue the calibration for Scale 1.
Now it is possible to perform calibration of any remaining scales,
or to return to normal weight display by pressing key ↑ several times.
Deadweight calibration
This is the most accurate calibration method. It requires that known weights
to at least two-thirds of the scale capacity are available.
A deadweight calibration should start with the common parameters,
described on page 26.
An asterisk ( * ) will be shown at the calibration parameters that have not yet
been stored.
This example shows a two-point deadweight calibration for Scale 1.
When deadweight calibration has been selected
and you have accepted to start a new calibration,
1:Calibr. Type
the display will show the type of calibration that is
Deadweight
selected for the scale.
Use keys + and – to find the parameter that should be edited.
Press key ↵ and the parameter value will be displayed with a cursor, ready to edit.
All parameters are explained on the following pages.
31
