Vishay G4 - Deadweight Calibration Points; Defining Number of Calibration Points; Setting First Calibration Point Load

Operating instructions, Quick installation
1:No of Cal. P
This parameter defines the number of calibration points. Up to six points can be
selected, parameters for load value and transducer signal will be displayed for
the selected number of calibration points.
In this example a two-point calibration is described.
If this parameter is selected for editing, the number
of calibration points appears on the bottom line
with a flashing cursor.
Use keys + and – to edit the number.
1:No of Cal. P
2
Press key ↵ for 1 second to accept the number.
The number of calibration points is displayed without
1:No of Cal. P
cursor.
2
Now key + or – can be used
to display another parameter.
1:Value Cal. P1
This parameter defines the load for the lowest calibration point. Normally the scale
should be unloaded and the parameter value set to 0 (zero). This weight value and
corresponding transducer signal value are automatically stored for the scale.
Press key ↵ .
The current gross weight is displayed as a live weight.
Press key ↵ .
1:Value Cal. P1*
0.0 kg
Gross Weight:
014.28
1:Value Cal. P1*
+000000.0 kg
1:Value Cal. P1
0.0 kg
The value +000000.0 kg, with a flashing cursor,
is proposed.
Press key ↵ for 1 second.
Parameter '1:Value Cal. P1' is displayed
without asterisk.
