Vishay G4 - Deadweight Calibration Loads and Signals; Setting Highest Calibration Load; Viewing Transducer Signals

G4 Multi Channel Weighing Instrument
1:Value Cal. P2
This parameter, in a two-point calibration, defines the load for the highest calibration
point. Normally the scale should be loaded to at least two-thirds of the scale capacity.
The weight value and the corresponding transducer signal value are automatically
stored for the scale.
Press key ↵ .
The current gross weight is displayed as a live weight.
Press key ↵ .
1:Value Cal. P2*
500.0 kg
Gross Weight:
196.52
Change the proposed value to the value of the actual calibration load on the scale
for calibration point 2.
Use key ↵ to move the cursor step by step.
Use key + or – to edit one cursor position at a time.
Accept the value of each position by pressing key ↵ .
Press key ↵ for 1 second to accept
the load value for point 2.
Parameter '1:Value Cal. P2' is displayed
without asterisk.
1:T.Signal P1
This parameter value shows the transducer signal
for point 1, a value that was automatically stored
at the lowest calibration point.
The parameter value can not be edited.
1:T.Signal P2
This parameter value shows the transducer signal
for point 2, a value that was automatically stored
at the highest calibration point.
The parameter value can not be edited.
1:Value Cal. P2*
+000200.0 kg
1:Value Cal. P2
200.0 kg
1:T.Signal P1
0.42971 mV/V
1:T.Signal P2
0.67298 mV/V
33
