Page 52 Vision Microsystems Incorporated
50.6
50.650.6
50.6
Volts
• low red
• low green
• high green
• high red
• Autotrack tolerance
• Alarm tolerance
50.7
50.750.7
50.7
Amps
• range marks desired
• low red (if chosen*)
• low green
• high green
• high red (if chosen*)
• Autotrack tolerance
• Alarm tolerance
50.8
50.850.8
50.8
Fuel computer
• range marks desired
• low red (if chosen*)
• low green
• high green
• high red (if chosen*)
• Autotrack tolerance
• Alarm tolerance
50.9
50.950.9
50.9
Fuel pressure
• range marks desired
• low red (if chosen*)
• low green
• high green
• high red (if chosen*)
• Autotrack tolerance
• Alarm tolerance
5 I.0
5 I.05 I.0
5 I.0
CHT
• 6 or 4 cylinder engine
• low green
• high green
• high red
• Autotrack tolerance
• Alarm tolerance
