DUETE-2/DuetD-2 USER MANUAL
PRODUCT S PECIFICATIONS
Visionary, Network Audio Video
54
Communication & Control of External Devices
Ethernet
Network connectivity for control and IP traffic pass-through to remote LAN devices
USB
USB 2.0 host or device signal extension and routing
GPIO
For extension and control of third-party devices
Serial / RS-232
Bi-directional device control and monitoring
IR
Device control via infrared
HDMI
HDCP 2.2, EDID (encoder), CEC (decoder)
Connectors
LAN 1
8-pin RJ-45 connector, female; 100BASE-TX / 1000BASE-T Ethernet port / PD port
POE+ (IEEE 802.3at), POE+ Only required for LAN2 PSE
LAN2
8-pin RJ-45 connector, female; 100BASE-TX / 1000BASE-T Ethernet port / PSE
port
POE (IEEE 802.3af)
HDMI INPUT 1 & 2 (Encoder)
(2) HDMI Type A connectors, female; HDMI digital video/audio inputs
HDMI Outputs (Encoder loop- through &
Decoder output)
HDMI Type A connectors, female; HDMI digital video/audio inputs
USB-C
Encoder input: (1) USB Type C connector, female; Decoder output: (1) USB
Type C connector, female;
6 pin Euroblock 3.81mm pitch connector
Shared GPIO / RS-232 / IR ports
USB Host (Decoder)
(2) USB Type-A connector, female; USB 2.0 host port; USB signal extender port
for connection to a mouse, keyboard, or other USB 2.0 device
USB Device (Encoder)
(1) USB Type-B connector, female; USB 2.0 device port; USB signal extender port
for connection to a computer or other USB 2.0 host
Power
Power Consumption
12 W typical
Environmental
Cooling
Convection / no fan ( no moving parts )
Temperature
32° to 104° F (0° to 40° C)
Humidity
10% to 90% RH (non-condensing)
Heat Dissipation
41 BTU/hr
Acoustic Noise
0 dBA
Form Factor
Dimensions
Height: 1.1 in. (28 mm)
Width: 5.75 in. (146 mm)
Depth: Encoder 6.89 in. (175 mm) Decoder 7.08 in. (180 mm)
Weight
1.0 lb (0.45 kg)
Compliance
CE, FCC, C-tick, RoHS, WEEE
