10
Advanced S
stem Information
The main menu shown below appears after the VS4500 is turned on and is used for accessing the Programming and
Administration menus. This menu is also used for sending a page to a receiver.
PAGE TO: 11:55
3.1 Administration Menu
From the Main Menu press the B key. Enter 4500 as password. The prompt Select Option will appear on the top line.
The Administration Menu provides access to the following available sub-menus:
1. Device Database
2. Time Setup
3. Date Setup
4. View Messages
5. Coverage Test
6. Time Zone Setup
7. Last Message
8. Reset Database
9. Sunset/Sunrise
A. Wireless Setup
B. Operations Modes
C. System Setup
D. TX Test Tone
To access a specific sub-menu, press the digit key representing it.
3.1.1 Device Database Menu
From the Administration Menu, select 1 followed by the # key. Following are the fields description:
Device to Edit
Enter 3 digit ID of the programmed device (001-899).
If the device already exists, its details will be displayed for editing or deleting.
Group devices (01-99) are represented and accessed by paging to devices 901-999.
Device Capcode
Enter the capcode of the programmed device. For Voice pagers, enter “0” followed by Tone A
and Tone B (for example, “0110111”).
Device Type
Select the type of the programmed device.
0
- Alphanumeric Pager
1 - Numeric Pager
2 - Tone Only Pager
3 - Voice Pager
4 - Wireless Speaker
5 - Widearea Pager (Note: Optional modem is required)
6 - Portable Radio
7 - Phone
8 - LED Display
9 - Intercom Station
Paging Mode
Select Mode and Baud Rate and press the # key:
1 – 512 bps, Mode 0
2 – 512 bps, Mode 1
3 - 512 bps, Mode 2
4 – 512 bps, Mode 3
5 – 1200 bps, Mode 0
6 – 1200 bps, Mode 1
7
- 1200 bps, Mode 2
8 – 1200 bps, Mode 3
9 – 2400 bps, Mode 1
0 – 2400 bps, Mode 2
Group
If the device is a member in a group, enter the group number (0-99) and press the # key.
Group devices are represented and accessed by paging to devices 901-999.
