visiplex VS4500 - System Setup Menu

16
D – LED Timeout Mode
Determines the default time slice that should be used to display messages sent to
alphanumeric displays. Enter a value according to the settings supported by the alphanumeric
display.
Note: Please refer to the alphanumeric display instructions sheet for more information.
Press the * key to return to the Administration Menu.
3.1.12 System Setup Menu
From the Administration Menu, select C followed by the # key. The following screen will be displayed:
SYSTEM SETUP:
COM1 PROTOCOL
This screen allows the administrator to configure the VS4500 as required for the application.
Press the key representing the field followed by # key to edit the settings. Following are the fields description:
1 – COM1 Protocol
Enter the serial communication protocol that should be used on COM1. Enter a value between
1 and 9 or A followed by # key to save the settings:
1 – TAP
2 – COMP1
3 – COMP2
4
– VISIPLEX
5 – GPS SYNC
6 – FREETEXT
7 – 900MHz Receiver
8 – VPR Receiver
9 – PC-ADMIN
A – WIDEAREA
2 – COM1 Baud Rate
Enter the serial communication settings (baud rate, parity, data bits, stop bits) that should be
used on COM1. Enter a value between 0 and 9, A or B followed by # key to save the settings:
0 – 300 bps, 7,E,1
1 – 300 bps, 8,N,1
2 – 1200 bps, 7,E,1
3 – 1200 bps, 8,N,1
4 – 2400 bps, 7,E,1
5 – 2400 bps, 8,N,1
6 – 9600 bps, 7,E,1
7 – 9600 bps, 8,N,1
8 – 19200 bps, 7,E,1
9 – 19200 bps, 8,N,1
A – 38400 bps, 7,E,1
B
– 38400 bps, 8,N,1
3 – COM2 Protocol
Enter the serial communication protocol that should be used on COM2. Enter a value between
1 and 9 or A followed by # key to save the settings:
1 – TAP
2 – COMP1
3 – COMP2
4
– VISIPLEX
5 – GPS SYNC
6 – FREETEXT
7 – 900MHz Receiver
8 – VPR-01 Receiver
9 – PC-ADMIN
A – WIDEAREA
4 – COM2 Baud Rate
Enter the serial communication settings (baud rate, parity, data bits, stop bits) that should be
used on COM2. Enter a value between 0 and 9, A or B followed by # key to save the settings:
0 – 300 bps, 7,E,1
1 – 300 bps, 8,N,1
2 – 1200 bps, 7,E,1
3 – 1200 bps, 8,N,1
4 – 2400 bps, 7,E,1
5 – 2400 bps, 8,N,1
6 – 9600 bps, 7,E,1
7 – 9600 bps, 8,N,1
8 – 19200 bps, 7,E,1
9 – 19200 bps, 8,N,1
A – 38400 bps, 7,E,1
B
– 38400 bps, 8,N,1
