42
General Information
6.1 Specifications
Encoder
Frequency Range VHF: 148-174 MHz, UHF: 403-433 MHz, 438-470 MHz
Data Baud Rate 512, 1200, 2400 BPS
Paging Format POCSAG (Narrow or Wide Band), 2-Tone
Paging Type Wireless Alphanumeric, Voice and Tone
Channel Spacing 12.5 kHz or 25 kHz
Power
AC Adaptor - Input: 100-240VAC, 50/60Hz
Output: 12VDC, 3A
Approvals UL/CSA listing (power supply)
Operating Temperature 32º to 104º F / 0º to 40º C
Storage Temperature 14º to 140º F / -10º to 60º C
Operating Humidity 10%-65%
Dimensions (W x H x D) 9.75" x 2.5" x 5.5" / 248mm x 63mm x 140mm
Weight 2.10 lbs. / 2.60 lbs with power supply
Warranty 1 Year, Parts and Labor
Internal Transmitter
RF Power Output VTX-6: 6W
Modulation Data and Tone: ± 3.5 kHz, Voice: ± 5.0 kHz
Frequency Stability
± 0.0025%, -22° to 140° F / -30° to 60° C
Reference Temperature: 77° F / 25° C
FM Noise Minimum 40dB below ± 3.0 kHz deviation at 1000 Hz
Spurious & Harmonic 75 dB
FCC Registration AIERIT11-450 (6W transmitter)
Telephone Line (optional)
Input Impedance
600Ω Nominal (Off-Hook)
Line Type Line Level (End to End Station Level), DTMF
Telephone Audio
DTMF Receive Level Dynamic Range: -26 dBm minimum
DTMF Receive Frequencies Tone (Nominal, ± 1.5%,± 2 Hz): 697, 770, 852,
941, 1209, 1336, 1477, 1633
