5 – USB Mode
Determines if the serial protocol used by the USB port. Enter a value between 1 and 2 followed
by # key to save the settings:
1
– VISIPLEX protocol
2 – PC-ADMIN protocol
6 – System Password
Enter the new administrator password that will be required to access the Administration Menu.
The default password is 4500.
7 – VOX Mode
Determines the sensitivity level and timeout interval for automated paging to the Auto Speaker
Paging device (usually 898). The Auto Speaker device will be activated when audio is detected
on the VOX port and transmission will be terminated when no audio is detected after the
timeout interval elapsed.
Low Sensitivity requires high audio input and High Sensitivity requires lower audio input.
Enter a value between 0 and 9 followed by # key to save the settings:
0
– Disabled
1 – VOX Mode 1 (High sensitivity, 4 seconds timeout)
2 – VOX Mode 2 (Medium sensitivity, 4 seconds timeout)
3 – VOX Mode 3 (Low sensitivity, 4 seconds timeout)
4 – VOX Mode 4 (High sensitivity, 8 seconds timeout)
5 – VOX Mode 5 (Medium sensitivity, 8 seconds timeout)
6 – VOX Mode 6 (Low sensitivity, 8 seconds timeout)
7 – VOX Mode 7 (High sensitivity, 16 seconds timeout)
8 – VOX Mode 8 (Medium sensitivity, 16 seconds timeout)
9 – VOX Mode 9 (Low sensitivity, 16 seconds timeout)
8 – PABX Voice
Determines if a voice prompt should be played when a user dials in to the system in order to
send a message using a phone keypad. Enter a value between 0 and 1 followed by # key to
save the settings:
0
– Disabled
1 – Enabled
9 – Time Stamp
Determines if a time stamp should be added to outgoing message. Enter a value between 0
and 1 followed by # key to save the settings:
0
– Disabled
1 – Enabled
A – RX Data Polarity
Determines if the receive data is inverted. Enter a value between 0 and 1 followed by # key to
save the settings:
0
– Normal
1 – Inverted
B – TX Data Polarity
Determines if the transmitter data should be inverted. Enter a value between 0 and 1 followed
by # key to save the settings:
0
– Normal
1 – Inverted
C – Pre-Sunset Time Determines the time offset in minutes from the sunset time. Enter a value from 0 to 99.
D – Past Sunrise Time
Determines the time offset in minutes from the sunrise time. Enter a value from 0 to 99.
Note: Sunset/Sunrise light control provides support for automated messaging to devices
based on the sunset and/or sunrise time of each day. The activation and deactivation time can
be set to an offset of 0 to 99 minutes before sunset and/or after sunrise time. The activated
devices will receive a command from the VS4500 at these times and perform a task such as
closing or opening dry-contacts.
Notes: 1. Underlined values indicate default values.
2. Standard paging protocols supported are Visiplex, TAP, COMP1 and COMP2.
3.2 Installation Mode Menu
Installation Mode forces the system to transmit the time information every minute. This mode is helpful when the system is
being installed or when conducting a site coverage test.
NOTE
: This feature is available only if Time Sync Mode was enabled. Installation Mode should be disabled after the
coverage test is completed to allow proper system operation.
From the Main Menu press the C key to enable and disable the Installation Mode. The following screen will be displayed:
SYNC IS ON
The display will return to the Main Menu. Press the C key again to disable the Installation Mode.
