Low Power System Installation Diagram
Medium Power System Installation Diagram
VS101-XX
VS4500
VS4500
A
pp
endices
5.1 Appendix A – Installation Diagrams
Data Cable
(DB25M – DB15M)
Coaxial Cable (BNC to BNC)
Magnetic Mount Antenna
(Optional Base Antenna)
Coaxial Cable (BNC to BNC)
Magnetic Mount Antenna
(Optional Base Antenna)
RJ-11 Telephone Interface
RS232 PC Interface
(External Transmitter
uses COM2
p
ort
)
Microphone
USB
AUX (Optional)
RF Out (Internal
Transmitter Only)
RS232 PC Interface
(External Transmitter
uses COM2
p
ort
)
Microphone
USB
AUX (Optional)
RF Out (Internal
Transmitter Only)
RJ-11 Telephone Interface
