SYSTEM CONNECTION DIAGRAM
ALARM CONNECTIONS
The Alarm connections are made via the push in connectors on the rear on the unit. There are 16
individual alarms inputs marked as Sensor In (1-16) and 2 Outputs marked as Alarm, plus 2 ground
connections. As shown below:
