2.13 SENSORS PNEUMATIC CYLINDERS - TYPE 1
FIGURE 2.21 MAGNETICALLY ACTUATED PROXIMITY SENSORS
Part nr. 38307
Description Sensor magnetic reed Festo SME-8-S-LED-24
B9 SelectFlux station 7 up
B10 SelectFlux station 7 down
B30 Lift in Outfeed station 4A up
B33 Select Nozzle 1A SelectWave on station 1
B34 Select Nozzle 1B SelectWave on station 1
B41 MultiWave cover 1 solderpot 1 closed
B43 MultiWave cover 2 solderpot 1 closed
B45 MultiWave cover 1 solderpot 2 closed
B47 MultiWave cover 2 solderpot 2 closed
B53 Select Nozzle 2A SelectWave on station 2
B54 Select Nozzle 2B SelectWave on station 2
B65 PCB-lift conveyor station 1 up
B66 PCB-lift conveyor station 2 up
B67 PCB-lift conveyor station 3 up
B68 PCB-lift conveyor station 4 up
B83 SecureGrip tilting B+
B86 SecureGrip tilting B-
