PARTS
44 CHAPTER 2
2.29 CABLES ROBOT AND MULTIFLUX UNITS
Cables in cableduct robot Cables in cableduct MultiFlux
506595 Motor Y-axis (M4) 506605 Motor Y-axis (M42)
506596 Encoder Y-axis(M4) 506606 Encoder Y-axis(M42)
506597 Motor Z-axis (M5) 506607 Sensor reference Y-axis (B32)
506598 Encoder Z-axis(M5) 506608 Dropjet valves (Y-splitter)
506599 Motor U-axis (M6)
506600 Encoder U-axis(M6)
506601 CDS net (Farnell connectors)
506602 CDS net (Farnell/AMP connector)
506603 Sensor reference Y-axis (B20)
506604 PT100 Y-axis (B6)
