Figure 9 Replacing a blown fuse
7 Flip the spare fuse out using
a pointy object..
8 Place the spare fuse in the
fuse carrier and click the fuse
in place.
11 The fuse carrier is in place
when you hear “CLICK”.
10 Push the fuse carrier into
the back.
9
6 Take the blown fuse out of
the fuse carrier and throw it
away.
