20
RD-101 | Version 1
3. operation
SETUP
Change the settings of the RD-101
OUTPUT
Change between XLR OUT and
RCA OUT.
BP VOL
Switch between BP OFF (enable
volume control) or BP On (disable
volume control).
DATA
Shows information about this
RD-101.
RESET
Restore the settings of the RD-101
to its default settings.
REMOTE
Change the settings of the Apple
Remote.
REMOTE ID
Show the ID of the remote.
UNPAIR
Un-pair the remote and the RD-
101 by removing the REMOTE ID
V.INIT
Change the initial dB step of the
volume in the RD-101 to any step
between -121.5 dB and 0 dB
VOL.STEP
The RD-101 has a default volume
step of 0 dB. You can set the
volume step to a step, between
-121.5 dB to 0 dB.This step will be
the new volume step. Even when
after the power cord has been
disconnected the RD-101 still
starts up in the new volume step.
REMEMBER
Set the RD-101 to remember
the current volume step. The
RD-101 will start up in this volume
step when it leaves standby.
This volume step however is not
remembered when the power
cord is removed. Then the RD-101
will initiate in the volume step as it
is defined in the V.INIT sub-menu.
BRIGHT
Change the brightness of the
display to any step between 0 and
3.
INPUTS
Change settings for each input.
INPUT X
Change the settings of input X.
USED
Select whether input X has to be
USED or not NOT USED.When
you select NOT USED input X will
not be shown in the list of inputs.
TEXT
Choose a name for input X.
OFFSET
Select an offset- gain, between
-12 and 12 dB, for input X.
SET FIX
Set the volume of input X to a
fixed dB step. (Input X is now
locked to a dB step and can not
be adjusted with the volume
control)
FIXED
Lock and unlock the volume by
switching between FIX ON/FIX
OFF.
ADJUST
Adjust the fixed dB step to any
step between -121.5.0 dB and 0
dB
RD-101 Menu: discription of the elements.
