Vitus Audio RD-101 - Example 7

42
RD-101 | Version 1
7. examples operating
RD-101 Left front panel
Example 7
Set the volume of
input 1 to a fixed vol-
ume step of -30 dB
You can set the volume of an
input to a fixed dB step. The input
is then locked to this dB step
and can not be adjusted with the
volume control.
Press the MENU button to
enter Menu Mode.
Navigate to the INPUT sub-
menu, using the function
buttons on the left front
1.  Scroll forward in the
menu.
2. MENU/ Enter & Exit
SELECT submenus and
selectsettings.
3.  Scroll backward in
the menu.
Navigate to the FIX sub-menu.
Select SET FIX and then select
FIX ON. Navigate to the SET
FIX submenu.
The SET FIX sub-menu
becomes available when FIX
ON has been selected.
The display now shows 0. This
is the volume step in which the
RD-101 initialises by default.
Adjust the volume step to -30 dB
and press the SELECT button. The
display now shows SET FIX.
Input X is now locked to the
choosen dB step and can not be
adjusted with the volume control.
If you want to set FIX OFF, then
repeate the sequence of the
example and select FIX OFF.
EXIT
SETUP
BACK
INPUTS
BACK
EXIT
Streamer
DIG
5
BACK
EXIT
FIXED
BACK
SET FIX
FIX OFF
FIX ON
SET FIX
ADJUST
O
-
3
O.O
ADJUST
SELECT
SELECT
SELECT
SELECT
SELECT
MENU
SELECT
SELECT
SELECT
