Vitus Audio RD-101 - 6 RD-101 Specifications; Specifications

32
RD-101 | Version 1
6. specifications
RD-101 Specifications
OUTPUT
ANALOG
XLR
Analog
RCA
Analog
Available 1 (L+R) 1 (L+R)
Impedance 2KΩ 2KΩ
Frequency
response
+800KHz +800KHz
Signal to
noise ratio
< 110dB < 110dB
THD +
noise
< 0,01% < 0,01%
VOLUME CONTROL
Type Digital volume
0.5 dB steps
Gain -121.5dB to 0dB
INPUT
DIGITAL
XLR
Digital
RCA
Digital
USB Streamer
Available 2 2 1 1
Sensitivity
2 V
RMS
1 V
RMS - -
Impedance 110Ω 75Ω - -
Slew rate 1000V/ μs 1000V/ μs 1000V/ μs 1000V/ μs
Sample rate 192 kHz 192 kHz 384 kHz 192 kHz
Resolution 24 bit 24 bit 32 bit 24 bit
POWER CONSUMPTION
Standby / Operation 30 W
RMS
DIMENSIONS
(H x W x D)
100 x 435 x 400 mm
Weight ~9 kg
DAC
Master
Clock
100
MHz
Frequency
tolerance
+/- 50
ppm
