Page #116 background imageLoading...
Page #116 background image
CONFIDENTIAL
DO NOT COPY Page 12-37
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
561 RN22 0141-7509-3851 ARRAY RES. A
(
X
)
75ohm 4R J 8P 1
562 RN23 0141-7509-3851 ARRAY RES. A(X) 75ohm 4R J 8P 1
563 RN24 0141-4709-3851 ARRAY RES. A(X) 47ohm 4R J 8P 1
564 RN25 0141-7509-3851 ARRAY RES. A(X) 75ohm 4R J 8P 1
565 RN26 0141-4709-3851 ARRAY RES. A(X) 47ohm 4R J 8P 1
566 RN27 0141-7509-3851 ARRAY RES. A(X) 75ohm 4R J 8P 1
567 RN28 0141-4709-3851 ARRAY RES. A(X) 47ohm 4R J 8P 1
568 RN29 0141-7509-3851 ARRAY RES. A(X) 75ohm 4R J 8P 1
569 RN30 0141-4709-3851 ARRAY RES. A(X) 47ohm 4R J 8P 1
570 RN31 0141-7509-3851 ARRAY RES. A(X) 75ohm 4R J 8P 1
571 RN6 0141-2209-3851 ARRAY RES. A(X) 22ohm 4R J 8P 1
572 RN7 0141-2209-3851 ARRAY RES. A(X) 22ohm 4R J 8P 1
573 RN8 0141-2209-3851 ARRAY RES. A(X) 22ohm 4R J 8P 1
574 RN9 0141-2209-3851 ARRAY RES. A(X) 22ohm 4R J 8P 1
575 RP23 0141-3309-3851 ARRAY RES. A(X) 33ohm 4R J 8P 1
576 RP24 0141-3309-3851 ARRAY RES. A(X) 33ohm 4R J 8P 1
577 RP3 0141-3309-3851 ARRAY RES. A(X) 33ohm 4R J 8P 1
578 RP4 0141-3309-3851 ARRAY RES. A(X) 33ohm 4R J 8P 1
579 RP5 0141-3309-3851 ARRAY RES. A(X) 33ohm 4R J 8P 1
580 R1 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
581 R10 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
582 R103 0130-5109-1654 RES. CF 51ohm 1/16W J 0402 1
583 R104 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
584 R106 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
585 R109 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
586 R11 0130-3302-1654 RES. CF 33Kohm 1/16W J 0402 1
587 R110 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
588 R112 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
589 R113 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
590 R114 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
591 R115 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
592 R116 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
593 R117 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
594 R118 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
595 R119 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
596 R12 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
597 R120 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
598 R121 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
599 R122 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
600 R123 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
601 R124 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
602 R125 0130-2209-1654 RES. CF 22ohm 1/16W J 0402 1
603 R126 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
604 R127 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
605 R128 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
606 R129 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
607 R13 0130-1800-1654 RES. CF 180ohm 1/16W J 0402 1
