Vizio VX32L - 364200220189 S Ir Bd Assy Gv42 L Hdtv Smd

CONFIDENTIAL – DO NOT COPY Page 12-17
File No. SG-0204
364200220189S IR BD ASS'Y GV42L HDTV SMD
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
1 0171-1671-0501 PCB IR BD FR4 66.5*12*1.6t D
(
GV42L HDTV
)(
1:20
)
1
2 CR2 0111-3106-1614 C/M Multi. 10uF 16V X7R K 1206 1
3 SS 0111-3106-1114 C/M MULTI 10uF 10V X7R K 1206
4 SS 0112-3106-1614 C/M MULTI 10uF 16V X7R 1206
5 SS 0115-7106-1614 C/M MULTI 10uF 16V X7R 1206
6 CR3 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
7 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
8 LR1 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
9 RR1 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
10 RR2 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
