Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 9-4
File No. SG-0204
Yes
Yes
N0
N0
N0
Yes
(
HDMI) IS NOT DISPLAY CORRECTLY
Input signal good?
Start
1.Check video
2.Check host’s setting
U31 input correct?
1.Check p10&p11 connect
2.Check signal between U31
and U19
U11 no data out ?
1.Check U11 power
2.Check between signal U19
and U11
3.Check U19 clock 27MHZ
1.Is J6 connected good?
2.Is panel working ok?
END

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
