Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-3
File No. SG-0204
3632-0052-0331 PANEL ASS'Y VX32L HDTV (LG)(ABS,433C)
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
1 0211-0320-1261 LCD MODULE 32.0'' LC320W01-SL01
(
LG.PHILIPS
)(
China
)
1
2 SS 0211-0320-1361 LCD MODULE 32.0'' LC320W01-SL01 (LG.PHILIPS)(Korea)
3 0260-0000-0221 AC INLET +VHR5P 1617#22 500mm 1015#18 100mm 1
4 0335-1008-0160 SPEAKER 10W 8ohm(126*56*55) +Wire 870/570mm (L,R) 1
5 0460-1004-0330 WH PH4P-PH4P 1061#26 130mm LF 1
6 0460-1012-0260 WH A2001H02-12P/A2001H02-12P 1061#26 150mm 1
7 0460-3010-0180 WH A1251H02-10P/A1251H02-10P 1571#28 350mm 1
8 0460-3430-0991
WH P240430/FI-X30H 20276#30 220mm+ 吸波材 *2
1
9 0460-4012-0020 WH A2543H12P-PH12P 1007#24 300mm 1
10 0460-4012-0170 WH A2543H00-12P/A2001H02-12P 1007#24 600mm 1
11 0460-4013-0070 WH A2543H13P-PH13P 1007#24 350mm CORE 1
12 0500-0502-0180 POWER BD ASS'Y 0601D03200 1
13 SS 0500-0507-0240 POWER BD ASS'Y DPS-199AP L-F
14 0950-0000-0010 License: Dolbly-AC3 Two-Channel Dolby Digital Deco 1
15 0950-0000-0020 License: MPEG-LA Consumer Products 1
16 0950-0000-0030 License: HDMI 1
17 0960-0000-0100 SOFTWARE MTK HDCP KEY w/mask CODE (China) 1
18 0980-0700-0071 LED BACKLIGHT 18*50 LYSB-4916W/SY-E 400mm 1
19 1701-1000-0430 BASE FOOT (TM-32V) 6
20 1701-1500-0690 WIRE SADDLE (CH-14) 2
21 1701-1500-1660 SPACER SUPPORT (DCB-6.5) 1
22 1701-1500-2500 CABLE CLIP(VX37L) 1
23 1701-1933-2010 SIDE JACK COVER (VX32L_LG)(ABS, SONY White) 1
24 1712-0100-4590 HEAT SINK FIX MTEAL (TM-30A) 1
25 1712-0101-0560 MAIN SHIELD (VX32L) 1
26 1712-0101-0590 WALL MOUNT SUPPORT (VX32L) 4
27 1712-0101-0620 BRACKET FOR AC SOCKET (VX32L HDTV) 1
28 1712-0101-1150 BKT FOR SUPPORT (VX32L) 2
29 1712-0101-1160 CHASSIS (VX32L_LG) 1
30 1712-0101-1170 PANEL HOLDER_L (VX32L_LG) 1
31 1712-0101-1180 PANEL HOLDER_R (VX32L_LG) 1
32 1712-0400-1920 HEAT SINK (VX37L HDTV) 1
33 1720-0003-0620 MAC. SCREW-MB M3.0*6.0L,Ni 20
34 1720-0004-1020 MAC. SCREW-MB M4.0*10.0L Ni 11
35 1720-1204-0820 MAC. SCREW-MPGW M4.0*8.0L,Ni 1
36 1720-1503-0620 MAC.SCREW-MPSWF M3.0*6.0L Ni 18
37 1720-1504-0820 MAC. SCREW-MPSWF M4.0*8.0L,NI 16
38 1720-3003-0820 MAC.SCREW-MF M3.0*8.0L,NI 2
39 1720-7344-0820 MAC. SCREW-MHSW #4-40*8.0L,Ni 2
40 1721-0003-0820 TAP. SCREW-TB #3.0*8.0L,NI 11
41 1721-0004-0820 TAP. SCREW-TP #4.0*8.0L,NI 15
42 1721-0004-1050 TAP. SCREW-TP #4.0*10.0L, BLK-Ni 6
43 1721-0004-1650 TAP. SCREW-TP #4.0*16.0L, BLK-Ni 8

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
