Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-4
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
44 1721-0045-1020 TAP. SCREW-TP #4.5*10.0L
,
Ni 2
45 1721-3003-0920 TAP. SCREW-MF M3.0*9.0L, Ni 2
46 1721-4104-1220 TAP. SCREW-TRF #4.0*12.0L,Ni 6
47 1801-0124-3011 FRONT BEZEL (VX32L)(ABS, Piano Black) ASS'Y 1
48 1801-0214-9010 REAR COVER (VX32L)(ABS,SONY White) ASS'Y 1
49 1801-0524-3010 BASE (VX37L HDTV)(ABS) ASS'Y 1
50 1947-1200-0310
ACETATE CLOTH TAPE ( 醋酸布膠帶 ) 27*75mm
1
51 1947-1200-0400
ACETATE CLOTH TAPE ( 醋酸布膠帶 ) 20*45mm
21
52 1947-1200-0820
ACETATE CLOTH TAPE ( 醋酸布膠帶 ) 60*45mm
1
53 1947-1200-3680
ACETATE CLOTH TAPE ( 醋酸布膠帶 ) 40*80mm
1
54 1947-1200-3870 MYLAR (18.0*28.0*0.6t)(VX32L) 1
55 1947-1200-3900 SPONGE (22.0L*55.0W*0.6t) 6
56 1947-1700-0130 SHIELDING AL.TAPE (70.0*50.0) 1
57 1947-1700-0550 SHIELDING AL. TAPE (100.L*45.0W*0.15T) 1
58 1947-1800-0030 GASKET BLOCK (10W*17H*60L) 6
59 1947-1800-0080 GASKET BLOCK (17*34*25mm) (773GT) 2
60 1947-1800-0460 GASKET BLOCK (3.0H*10.0W*100.0L mm) 2
61 1947-1900-0030 HEATPATH (25x14mm) 1
62 3632-0012-0156 DISPLAY BD ASS'Y VX32L HDTV 1
63 3632-0022-0146 CONNECTOR BD ASS'Y VX32L HDTV 1
64 3632-0062-0150 MAIN BD ASS'Y VX32L HDTV_LG (HDCP) 1
65 3642-0022-0189 IR BD ASS'Y GV42L HDTV 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
