Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 4-1
File No. SG-0204
Chapter4 Factory preset timings
This timing chart is already preset for the TFT LCD analog & digital display
monitors.
Resolution
Refresh
rate
Horizontal
Frequency
Vertical
Frequency
Horizontal
Polarity
Vertical
Polarity
Pixel
Rate
640x480 60Hz 31.5kHz 59.94Hz N N 25.175
640x480 75Hz 37.5kHz 75.00Hz N N 31.500
800X600 60Hz 37.9kHz 60.317Hz P P 40.000
800x600 75Hz 46.9kHz 75.00Hz P P 49.500
800X600 85Hz 53.7kHz 85.06Hz P P 56.250
1024x768 60Hz 48.4kHz 60.01Hz N N 65.000
1024X768 75Hz 60.0kHz 75.03Hz P P 78.750
720x400 70Hz 31.46kHz 70.08Hz N P 28.320
1366X768 60 47.7KHZ 60.00HZ P N 85.500
Remark: P: positive N: negative

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
