Page #89 background imageLoading...
Page #89 background image
CONFIDENTIAL
DO NOT COPY Page 12-10
File No. SG-0204
363200120156M DISPLAY BD ASS'Y VX32L HDTV MI
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
1 CON1 0451-1250-1066 WAFER 1.25mm 10P 90' DIP KINK
(
M240110R
)
L-F 1
2 SS 0451-1250-1063 WAFER 1.25mm 10P 90' KINK (A1251WR0-10P) L-F
3 CON3 0451-1250-0366 WAFER 1.25mm 3P 90' DIP KINK (M24013R) L-F 1
4 SS 0451-1250-0363 WAFER 1.25mm 3P 90' KINK (A1251WR0-3P) L-F
5 J2 0451-2000-0466 WAFER 2.0mm 4P 90' DIP KINK (M24264R) L-F 1
6 SS 0451-2003-0463 WAFER 2.00mm 4P 90' KINK (A2001WR2-4P) L-F
7 SW1 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
8 SW2 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
9 SW3 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
10 SW4 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
11 SW5 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
12 SW6 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
13 SW7 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
