Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 2-1
File No. SG-0204
Chapter 2 Specification
1. LCD CHARACTERISTICS
LC320W01
Item Specification
Active Screen Size
31.51(800.4mm) inch diagonal
Outline Dimension
760.0mm(H) x 450.0mm(V) x 48.0mm(D) (Typ.)
Pixel Pitch
0.17025mm x 0.51075mm xRGB
Pixel Format 1366 (R,G,Bx3) x 768
Display Color 16.7 M (8-bit + FRC for R,G,B)
Luminance, White 500 cd/m
2
(Typ)
Viewing Angle(L/R/U/D) 89/89/89/89
Power Consumption 84 Watt (Typ.) (Vdd line +CCFL line)(at 3.5A)
Weight 6900g (Typ)
Display Mode Transmissive mode, normally black
Surface Treatment Hard coating(3H), AG
2. OPTICAL CHARACTERISTICS
Viewing Angle (CR>10)
Left: 89°typ.
Right: 89°typ.
Top: 89°typ.
Bottom: 89°typ.
3. SIGNAL (Refer to the Timing Chart)
Sync Signal
1) Type: TMDS
2) Input Voltage Level: 100~240 Vac, 50/ 60 Hz
4.Input Connectors
RJ11, D-SUB15PIN (MINI, 3rows), HDMIX2, RCAX2 (component), RCAX2 (AUDIO
in), RCAX2 (composite), RCAX2 (AUDIO in), S-Video, Tuner
Output Connectors
Analog audio out (Stereo RCA Jack) , Digital audio out (Optical)

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
