Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 11-1
File No. SG-0204
Chapter 11 Spare Parts List
PART NO DESCRIPTION LOC QTY REMARK
0185-1302-0073 FUSE 125V/3A SMD (R451003) LF F1, F2 2
0320-4000-0142 POWER CORD 110V UL/CSA 1800mm BLK N.M. (VINC) 1
0321-0000-0411 AV CABLE RCA(Y/W/R) 1800mm BLK (VINC) 1
0360-1000-0420 POWER INDUCTOR L:10uH 1.44A 5.8x5.2mm SMD LF L26 1
0390-6005-2103 SCHOTTKY DIODE 0.5A/40V MBR0540T1G SOD-123 LF D5 1
0410-5000-5610 TRANSISTOR MMBT3904LT1G SOT-23 L-F
Q1, Q10, Q11, Q13,
Q15, Q16, Q17, Q18,
Q19, Q2 , Q21, Q22,
Q24, Q26, Q3, Q4,
Q5, Q8, Q9
19
0410-5000-5611 TRANSISTOR PMBS3904 SMD T LF
0410-5000-5710 TRANSISTOR MMBT3906LT1G SOT-23 L-F Q12, Q14, Q23, Q25 4
0410-5000-5711 TRANSISTOR PMBS3906 SMD LF
0420-1005-4601 POWER MOS IRF7316TRPBF SMD 8PIN LF U1, U32 2
0420-2005-8635 MOSFET 3.6A 30V AM2343P-T1-PF SOT-23 3PIN LF QF3 1
0430-4013-3109 IC TDA8946AJ 17PIN DIP LF U31 1
0430-6006-1079 IC LDO AP1084KLA ADJ TO-263-3L LF U10 1
0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF
U2, U33, U4, U7, U8,
U9
6
0430-6011-3204 IC LM7805CT TO-220 3PIN LF
0430-6011-3210 IC MC7805CTG 3PIN TO-220 LF U3 1
0430-6015-6099 IC RESET STL8110GCL438 4.38V SOT-23 3PIN LF U15 1
0430-6015-8079 IC DC/DC CONVERTER AP1522WA SOT23-5 5PIN LF U34 1
0430-7043-1999 IC DEMODULATOR MT5112BD LQFP 100PIN LF U13 1
0430-7043-5092 IC SWITCH PI5C3257QE QSOP 16PIN LF U24 1
0430-7043-6999 IC SCALER MT5372AJ-L BGA 588PIN LF U14 1
0430-7044-1092 IC SWITCH PI3HDMI412FTZHE TQFN 42PIN LF U22 1
0980-0103-3060 MODULE TUNER DTVS205CH201A L-F U12 1
1801-0124-3011 FRONT BEZEL (VX32L)(ABS, Piano Black) ASS'Y 1
1801-0214-9010 REAR COVER (VX32L)(ABS,SONY White) ASS'Y 1
1801-0524-3010 BASE (VX37L HDTV)(ABS) ASS'Y 1
1925-1000-3500 EPS FOAM_TL (VX32L) 1
1925-1000-3510 EPS FOAM_TR (VX32L) 1
1925-1000-3520 EPS FOAM_BL (VX32L) 1
1925-1000-3530 EPS FOAM_BR (VX32L) 1
1925-1100-0230 PE BAG 320*230*0.04T 2
1925-1100-0280 PE BAG (180W*290L*0.04t)(PE-LD)(ACC.-1) 1
1925-1100-2320 PE BAG (VX32L HDTV) 1
1925-1200-7080 ACCESSARY BOX (330W*230D*50H) 1
1925-1200-9060 CARTON TRAY (VX32L) 1
1925-1200-9190 CARTON VIZIO VX32L HDTV 1
1925-1300-7080 Brochure VIZIO Series 1
1925-1300-7980 Quick Setup Guide VIZIO VX32L HDTV 1
1925-1300-7990 MANUAL VIZIO VX32L HDTV 1
1925-1400-2710 Register CARD/VIZIO L15 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
